Patrol 860

The Patrol is a commercial quality range of RIBs designed and hand built to withstand the toughest conditions.

The hull is built in 5mm 5083 aluminium plates with 6 and 10mm stringers. With their super deep V, wide chines and large diameter tube, they offer high maneuverability, high safety and a soft dry ride even in the roughest conditions.

The Patrol boats carry large loads and plane quickly and easily with little horsepower.

These boats are ideal pursuit craft or work boat and can be configured with different seating and console options.

When safety, toughness and reliability matter the Patrol range will be your first choice.

Standard features

  • ORCA® Hypalon tube fabric
  • High tensile chromated & powder coated aluminum hull
  • Stand-up console & leaning post
  • Integrated rear seat with cushion
  • Flush mount non-return valves
  • Self-draining deck
  • Integrated under-deck fuel tank of 470L
  • Bow step with mooring cleat and roller
  • Bow locker with seat cushion
  • Lifting points and towing eyes
  • Anti-slip deck
  • Engine well
  • Heavy duty rubbing strake & keel guard
  • Highfield dry bag, foot pump, paddles, repair kit

Optional Equipment

  • Roll bar
  • Jockey seat
  • Teak deck
  • Removable teak table
  • Leaning post foldable table
  • Ladder
  • Inflatable sundeck


Overall Length 8.63 m 28' 3"
Internal Length 6.92 m 22' 8"
Overall Width 2.92 m 9' 6"
Internal Width 1.75 m 5' 8"
Dead Rise 24°
Tube Diameter 56 cm 22"
Number of Air Chambers 6
Maximum Load 2000 kg 4410 lb
Maximum People 20
Boat Only Weight 1040 kg 2292 lb
Recommended Power 2*200 hp
Maximum Power 2*250 hp
Engine Shaft XL
Fuel Tank 400 l 124 gal
Design Category C
